IQT3 Pro part-turn 3-phase, 1-phase and DC electric actuators are designed for isolation or regulation duties (S2 & S3/Class A & B) of up to 1,200 starts per hour. Direct torque output range from 50 Nm to 3,000 Nm (37 lbf.ft to 2,214 lbf.ft) Electrical Supply: 1-phase 3-phase DC Actuator Type: Part-turn Isolating / regulating duty On-off & inching Duty Cycle: 1,200 starts/hour S2/S3 — 25% duty Class A+B Torque Range: 50 — 3,000 Nm
Технические характеристики
CharacteristicsTypeelectricMovementpart-turnPhasethree-phase, single-phaseOther characteristicsDCTorque
Min.: 50 Nm (36.88 ft.lb)
Max.: 3,000 Nm (2,212.69 ft.lb)
