Технические характеристики
| Type number | C11090-22B |
|---|---|
| Camera head type | Hermetic vacuum-sealed head *1 |
| Imaging device | Frame transfer CCD |
| Effective no. of pixels | 1024 (H) × 1024 (V) |
| Cell size | 13 μm (H) × 13 μm (V) |
| Effective area | 13.3 mm (H) × 13.3 mm (V) |
| Full well capacity | 80 000 electrons |
| Readout speed | 3.15 frames/s |
| Readout noise | 6 electrons rms（typ.）*4 |
| Pixel clock rate | High-precision readout mode: 0.3125 MHz High speed readout mode: 5 MHz |
| Exposure time | Internal synchronous mode/High-precision readout mode: 3.53 s to 7200 s *6 *7 Internal synchronous mode/High speed readout mode: 307 ms to 7200 s *6 External synchronous mode/High-precision readout mode: 400 ms to 7200 s *6 External synchronous mode/High speed readout mode: 20 ms to 7200 s *6 |
| Cooling method | Forced-air cooled Water cooled |
| Cooling temperature | Forced-air cooledl:- 65 ˚C (Ambient temperature : 0 ˚C to +30 ˚C)*2 Water cooled: -75 ℃ (Water temperature: +20 ℃) *2 *3 |
| Dark current | Air cooled (cooling temperature: — 65 ˚C): 0.0065 electron/pixel/s (typ.) Water cooled (cooling temperature: — 75 ˚C): 0.0012 electron/pixel/s (typ.) |
| Dynamic range | 13 333:1 *5 |
| Sub-array | Yes |
| Binning | 2 × 2, 4 × 4, 8 × 8 |
| External trigger mode | Edge trigger, Level trigger, Start trigger, Synchronous readout trigger *8 |
| Trigger output | 3 programmable timing outputs, Exposure timing output, Trigger ready output *8 |
| Interface | IEEE 1394b-2002 |
| A/D converter | 16 bit |
| Lens mount | C-mount |
| Power supply | AC 100 V to 240 V, 50 Hz / 60 Hz |
| Power consumption | Approx. 120 VA |
| Ambient operating temperature | 0 ℃ to +40 ℃ |
| Performance guaranteed temperature | 0 ℃ to +30 ℃ |
| Ambient storage temperature | -10 ℃ to +50 ℃ |
| Ambient operating humidity | 30 % to 70 % Forced-air cooled (with no condensation) |
