The F-SA-C Single-Mode Fiber is all-glass and supports single-mode light propagation for a 488 — 633 nm operating wavelength range. This low attenuation, step-index fiber has a uniform core refractive index and a matched-clad profile. It has a 0.10 to 0.14 NA, a 3.4 &mu,m Mode Field Diameter, a 125 &mu,m Cladding Diameter and a 245 &mu,m Coating Diameter. Typical applications include sensors, instrumentation, device pigtailing, and light delivery.
This fiber has a 900 &mu,m jacket surrounded by a layer of Aramid yarn for extra protection. A 2.5 mm outer PVC cable jacket provides additional environmental protection. Standard pricing is per meter.
Технические характеристики
- Index Profile Step
- Fiber Type Singlemode
- Fiber Jacket Yes
- Mode Field Diameter, Nominal 2.8 — 4.1 m @488 nm
- Cladding Diameter 125 ±1 m
- Coating Diameter 245 ±15 m
- Cable Diameter 2.5 mm
- Operating Wavelength 488 — 633 nm
- Cut-off Wavelength 350 — 450 nm
- Buffer Coating Material Dual Acrylate
- Maximum Attenuation 50 dB/km @488 nm
- Numerical Aperture 0.10 — 0.14
- Proof Test 100 kpsi
