The EDF-T3 C-band Erbium Doped Fiber provides low splice loss, high strength enhanced overlap integrals and pumping at 980nm and 1480 nm.
The model will be obsolete upon depletion of stock. A replacement model is F-EDF-2.
Standard pricing is per meter.
Технические характеристики
- Fiber Type Erbium Doped
- Mode Field Diameter, Nominal 4.9 — 6.5 m
- Cladding Diameter 125 ±1 m
- Coating Diameter 245 ±10 m
- Cut-off Wavelength 1100 — 1250 nm
- Buffer Coating Material Dual Acrylate
- Maximum Attenuation 7 dB/km
- Numerical Aperture 0.21 — 0.25
- Proof Test 100 kpsi
- Absorption at Pump/Peak 5.0 — 8.0 dB/m
