Технические характеристики
- Diameter 12.5 mm
- Material Excimer Grade UV Fused Silica
- Antireflection Coating 355 nm
- Surface Flatness &lambda,/10 @ 632.8 nm
- Surface Quality 10-5 scratch-dig
- Thickness 3.0 mm
- Thickness Tolerance ±0.10 mm
- Wavefront Distortion &lambda,/20 @ 632.8 nm, transmitted
- Parallelism 5 arc seconds
- Cleaning See How to Clean Optics
- Clear Aperture Central 90% of diameter
- Diameter Tolerance +0/-0.10 mm
- Angle of Incidence 0°
- Damage Threshold 4 J/cm², 10 ns pulses @ 355 nm
