The M-RS2000D-46-8 Double Density Research Grade Optical Table is identical to the RS2000 series in every way except for a unique double-density hole grid pattern that is ideal for applications requiring a dense mounting surface, such as laser cooling, atomic physics, and spectroscopy. Due to the unmatched low frequency superiority of Newport vibration absorber tuned damping technology, its performance easily rivals the performance of other top-of-the-line table tops on the market. This 203 mm thick optical table has a 1200 mm width, a 1800 mm length, and M6 holes on a 25mm, double density grid. Its supreme stability has meant the difference between success and failure in countless leading edge applications where stringent vibration protection on a limited budget is required.
Технические характеристики
- Tuned Damping 2 Narrowband Precision Tuned Dampers
- Broadband Damping Constrained layer core, damped working surface and composite edge finish
- Width 1200 mm
- Length 1800 mm
- Thickness 203 mm
- Working Surface 4.8 mm thick 400 series ferromagnetic stainless steel
- Surface Flatness ±0.1 mm over 600 mm square
- Mounting Holes M6
- Mounting Hole Pattern 25 mm grid, double density
- Alpha-Numeric Grid Labels No
- Mounting Hole Borders 12.5 mm
- Hole Sealing Type Easy clean conical cup, 16 mm deep, non-corrosive high impact polymer material
- Core Design Trussed honeycomb, vertically bonded closed cell construction, 0.25 mm steel sheet materials, 0.76 mm triple core interface
- Bottom Skin Material 4.8 mm thick carbon steel
- Non-Magnetic Surface No
- Weight 300 kg
- Crated Weight 372 kg
