The SA2-06X12-D Solid Aluminum Optical Breadboard is a 6 x 12 inch by 0.5 inch thick solid aluminum plate perfect for all kinds of non-critical applications where higher performance and higher priced breadboards are simply not necessary. It features double density hole pattern to accommodate the ever growing need to mount components more closely together to save space for compact applications.
Технические характеристики
- Width 6 in.
- Length 12 in.
- Thickness 0.5 in.
- Working Surface Low reflective anodized aluminum
- Surface Flatness ±0.02 in.
- Microlocks No
- Mounting Holes 1/4-20
- Number of Counterbored Holes Four 1/4 in. Located at corners — Inset 0.5′ from edge
- Mounting Hole Type Cut (not rolled) threads with countersink
- Mounting Hole Pattern 1.0 in. grid, double density
- Mounting Hole Borders 0.5 in. borders
- Core Design Solid Aluminum
- Weight 3.5 lb
