The M-SA2-06X36 Solid Aluminum Optical Breadboard offers a combination of durability, quality workmanship, and affordability. This 13 mm thick, 150 mm x 900 mm solid aluminum plate is perfect for all kinds of non-critical applications where higher performance and higher priced breadboards are simply not necessary. A wide variety of breadboard accessories make it easy to incorporate these breadboards into larger optical systems with ease.
Технические характеристики
- Width 150 mm
- Length 900 mm
- Thickness 12.7 mm
- Working Surface Low reflective anodized aluminum
- Surface Flatness ±0.5 mm
- Microlocks No
- Mounting Holes M6
- Number of Counterbored Holes Four M6 Located at corners — Inset 12.5 mm from edge
- Mounting Hole Type Cut (not rolled) threads with countersink
- Mounting Hole Pattern 25 mm grid
- Mounting Hole Borders 12.5 mm borders
- Core Design Solid Aluminum
- Weight 4.6 kg
