Охлаждающие циркуляционные термостаты с подогревом (программа)

Product Description Newly developed bath circulator with the Intelligent programmable controller. Intelligent program control 10 programs available for temperature ramp up and dwell control. 10 steps per a program and 99 hours 59 minutes per a step. Stored programs are easily linkable. Programs can be repeated up to 99 cycles. Pre-heating and heating time are settable before program starts. Performance Temperature range. RW3-35P models from -35C to 150C. RW3-25P models from -25C to 150C. Microprocessor PID control. Three point temperature calibration / Automatic tuning / Automatic run. Suitable for both internal and external bath environments due to reduced turbulence by using five-speed adjustable pump and built-in cooling coil. (1 to 3 steps of the pump for internal circulation and 4 to 5 steps for external circulation) Pump Step 1 2 3 4 5 Max. pressure (psi) 0.5 1.1 2.4 4.9 5.9 Max. flow rate (L/min) 5.6 8.0 12.8 18.8 28.0 Convenience Intuitive touch screen LCD controller with easy icons and logical menus. Dual wait on/off timer modes. (1 min. to 99 hr. 59 min.) Digital input and output control function for interlocking external devices. RS-232 / USB interface for external control and data collection. Corrosion-resistant, leak-proof, round-cornered, and easy-to-clean stainless steel bath with easy access drain valve. Detachable condenser air-filter for easy maintenance of refrigerating efficiency. Usage of CFC-free refrigerant (R-507, R-404A) and a double service valve for leakage prevention. Quick-release front grill for easy cleaning of the condenser. Built-in casters and side handles for easy transport and installation. Monitor via mobile app anytime, anywhere with LC Connected (mobile monitoring system) connection. (when purchased LC GreenBox) Touch LCD Controller Safety Isolated design of agitator, heater, and sensor by a baffle plate to minimize the turbulence in the bath fluid and also to protect users and samples against direct contact. Temperature warning Indicator simply shows inner reservoirs temperature by three different colors. Complete safety protection system with warning alarms. Low fluid level and dry-running, over-temperature, over-current. Keypad lock function prevents accidental changes during operation. Splash-proof keypad. Specifications for temperature range from -25 to 150 Model RW3-0525P RW3-1025P RW3-2025P RW3-3025P Bath volume (L / cu ft) 5 / 0.2 10 / 0.4 20 / 0.7 30 / 1.1 Temperature Working temperature range ( / ) -25 to 150 / -13 to 302 Temperature stability 1) (&plusmn, / ) 0.05 / 0.09 Cooling capacity 2) (bath fluid: ethanol) at +20 (+68), W 320 380 550 740 at 0 (+32), W 230 270 420 630 at -20 (-4), W 80 150 300 470 Pump(bath fluid: water) Max. pressure 5.9 PSI (406.8 millibar) Max. flow rate 7.4 gallons / minute (28 liters / minute) Dimension Bath opening / depth(WL, D) (mm / inch) 15099, 160/ 5.93.9, 6.3 211154, 180/ 8.36.1, 7.1 290214, 200/ 11.48.4, 7.9 300264, 230/ 11.810.4, 9 Exterior(WLH) (mm / inch) 308x480x733/ 12.118.928.9 366x532x780/ 14.420.930.7 386x602x825/ 15.223.732.5 446x662x895/ 17.626.135.2 Net weight (kg / lbs) 38 / 83.8 44 / 97 60 / 132.2 67 / 147.7 Electrical requirements (230V, 60Hz) 11A 11A 12.5A 13.5A Cat. No. AAH57642K AAH57652K AAH57662K AAH57671K Electrical requirements (230V, 50Hz) 11A 11A 12.5A 13.5A Cat. No. AAH57642K AAH57652K AAH57662K AAH57672K Electrical requirements (120V, 60Hz) 12.6A 12.6A Cat. No. AAH57643U AAH57653U for temperature range from -35 to 150 Model RW3-0535P RW3-1035P RW3-2035P RW3-3035P Bath volume (L / cu ft) 5 / 0.2 10 / 0.4 20 / 0.7 30 / 1.1 Temperature Working temperature range ( / ) -35 to 150 / -31 to 302 Temperature stability 1) (&plusmn, / ) 0.05 / 0.09 Cooling capacity 2) (bath fluid: ethanol) at +20 (+68), W 280 450 800 880 at 0 (+32), W 150 330 660 700 at -20 (-4), W 80 150 400 440 Pump(bath fluid: water) Max. pressure 5.9 PSI (406.8 millibar) Max. flow rate 7.4 gallons / minute (28 liters / minute) Dimension Bath opening / depth(WL, D) (mm / inch) 15099, 160/ 5.93.9, 6.3 211154, 180/ 8.36.1, 7.1 290214, 200/ 11.48.4, 7.9 300264, 230/ 11.810.4, 9 Exterior(WLH) (mm / inch) 308x480x733/ 12.118.928.9 366x532x780/ 14.420.930.7 386x602x825/ 15.223.732.5 446x662x895/ 17.626.135.2 Net weight (kg / lbs) 38 / 83.8 44 / 97 60 / 132.2 67 / 147.7 Electrical requirements (230V, 60Hz) 12.5A 12.5A 13.5A 14.5A Cat. No. AAH57742K AAH57752K AAH57761K AAH57771K Electrical requirements (230V, 50Hz) 12.5A 12.5A 13.5A 14.5A Cat. No. AAH57742K AAH57752K AAH57762K AAH57772K Technical data (according to DIN 12876) In case using silicon oil, you need to exchange other material tube (inlet and out late part), such as copper tube, a teflon tube instead of a silicon tube in fitting. 1) Technical data according to DIN 12876. (bath fluid : ethanol at -10) 2) The cooling capacity is measured under 230V / 60Hz electrical condition.

Технические характеристики

Technical Specificationsfor temperature range from -25℃ to 150℃

for temperature range from -35℃ to 150℃

※ Technical data (according to DIN 12876)

※ In case using silicon oil, you need to exchange other material tube (inlet and out late part), such as copper tube, a teflon tube instead of a silicon tube in fitting.

1) Technical data according to DIN 12876. (bath fluid : ethanol at -10℃)
2) The cooling capacity is measured under 230V / 60Hz electrical condition.
