OEM#: WINL97-4.5/1-213/5TCHELICAL INLINE REDUCER, 213/5TC INPUT FLANGE, 4.5:1 RATIO by Worldwide Electric Corporation

434 250

Worldwide Electric WINL97-4.5/1-213/5TC, Helical Inline Speed Reducer, 213/5TC Input Flange, 4.5:1 RatioCast-Iron, Helical Inline Speed Reducers are available in box sizes 37-147 to support 1/4 HP to 100 HP NEMA frame motors in speed ratios from 2:1 to 120:1. The units have NEMA motor quill style input flanges and solid output shafts, come pre-filled with mineral oil and have a 2 year warranty. Special features include ball bearings on the input and output shafts and precision ground gears for better rotation and quieter operation.

Доставка импортных компонентов по России от 3х недель транспортными компаниями СДЭК, Деловые Линии, Major Express.
Оплата физическими и юридическими лицами безналичным расчетом.
Цена может измениться после запроса у поставщика!
Артикул: HomeWorldwide Electric CorporationWINL974512135TC TME арт.: HomeWorldwide Electric CorporationWINL974512135TC

P/N: WINL97-4.5/1-213/5TC Key Specs

Item
HELICAL INLINE REDUCER, 213/5TC INPUT FLANGE, 4.5:1 RATIO
OEM
Worldwide Electric Corporation
OEM #
WINL97-4.5/1-213/5TC
Condition
New OEM Original
Returnable
No
Actual Gear Ratio
4.42
Box Size
97
Cross Reference
SEW RX97
Gear Ratio
4.5:1
Gear Stages
1
Max Input Hp
18.4
Max Torque (In-Lbs.)
2821
Nema Frame
213/5TC
Output Speed (Rpm)
396
Overhung Load Lbs.
1322
