P/N: WD34C1JC Key Specs
Item
MOTOR 3/4 HP 3600 56C 115/208-230V
OEM
U.S. Motors
OEM #
WD34C1JC
Condition
New OEM Original
Returnable
No
Body Diameter
6.3 in
CC Number
CC030A
Duty Cycle
Continuous
Frame
56C
Full Load Amps
9.7/5.3-4.9
HP
3/4
Hz
60
Ins. Class
F
Length Less Shaft
10-3/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
Washdown
Motor Bearings
Ball
Motor Design
Capacitor-Start
Motor Efficiency Group
Standard Efficient
Motor Enclosure Design
Totally Enclosed Nonventilated
Motor Frame Material
Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CCW, CW
Motor Sub Application
Garage/Gate Opener
Motor Thermal Protection
Auto
NEMA Design
N
Nameplate RPM
3,600
Nominal Efficiency
81.6 %
Number of Speeds
1
Overall Length
12-1/4 in
Phase
Single
Shaft Diameter
5/8 in
Shaft Length
2-1/16 in
Shaft Material
Stainless Steel
Standards
CSA (156060), UL (E22922)
Usable @ 200V
No
Usable @ 208V
Yes
Voltage
115/208-230V AC
Weight
30 lb
