P/N: WCV1600ES Key Specs
Item
WAFER CHECK VALVE PVC 6 FLANGE
OEM
Hayward
OEM #
WCV1600ES
Condition
New OEM Original
Returnable
No
Application — Valves
Process Piping
Body Material — Valves
PVC
Connection Type — Check Valves
Flange x Flange
Cracking Pressure — Check Valves
1 psi
Flow — Valves
1,000 gpm
Flow Design
Single
Full Flow — Valves
Yes
Item — Check Valves
Check Valve
Length
3 in
Max Steam Pressure — Valves
Not Rated
Max Temperature — Valves
140 Degrees F
Max Water Pressure — Valves
150 psi @ 70 Degrees F
Mechanism and Body Design
Inline Wafer
Min Temperature — Valves
40 Degrees F
Mounting Orientation — Check Valves
Horizontal, Vertical
Overall Height
11-1/8 in
Pipe or Tube Size — Check Valves
6 in
Seal Material — Check Valves
EPDM
Seat Material — Check Valves
EPDM
Spring Material — Check Valves
Stainless Steel
Width
8-5/8 in
