Name: OEM#: W573SEVERE DUTY MOTOR, 324THFS9026, 40HP, 460V, 1800RPM, 3PH, 324T FR, TEFC by Marathon Motors
SKU: HomeMarathon MotorsW573
Availability: InStock

OEM#: W573SEVERE DUTY MOTOR, 324THFS9026, 40HP, 460V, 1800RPM, 3PH, 324T FR, TEFC by Marathon Motors

1 305 675 ₽

Marathon Motors Severe Duty Motor, W573, 324THFS9026, 40HP, 460V, 1800RPM, 3PH, 324T FR, TEFCMarathons 1800 Rpm, line of Severe Duty Neman Premium XRI Duty IEEE-841 Hazardous Duty Motor are available in TEFC construction. Horsepower sizes available from stock range from 1 HP through 350 HP.

Доставка импортных компонентов по России от 3х недель транспортными компаниями СДЭК, Деловые Линии, Major Express.

Оплата физическими и юридическими лицами безналичным расчетом.

Цена может измениться после запроса у поставщика!

Артикул: HomeMarathon MotorsW573 TME арт.: HomeMarathon MotorsW573

Marathon Motors

P/N: W573 Key Specs

Item

SEVERE DUTY MOTOR, 324THFS9026, 40HP, 460V, 1800RPM, 3PH, 324T FR, TEFC

OEM

Marathon Motors

OEM #

W573

Condition

New OEM Original

Returnable

60 Hertz Kw

60 Hertz Rpms

1800

Ambient Temp C

Assembly

F1 (F2 Modification Available)

Bearing-Drive-End

6312

Csa

Drive End Bearing Size

6312

Duty

Continuous

Enclosure

TEFC

Enclosure Type

Totally Enclosed

Fl Amps

47.5

Fl Efficiency

94.1

Frame

324T

Hazardous Location

DIVISION 2 T2B

Horsepower

Insulation Class

Inverter Speed Range

Constant 2:1

Ip Code

Is_Motor

Yes

Kva-Code

Model Number

324THFS9026

Motor Rpm 60Hz

1800

Mounting

Rigid

Nema Design

Opposite End Bearing

6311

Opposite End Bearing Size

6311

Orientation

Horizontal

Phase

Rpm

1800

Rpm Range

1701-1800

Service Factor

1.15

Starting Type

Line or Inverter

Recognized Construction

Voltage

460

Weight

710
