P/N: VEL11318 Key Specs
Item
MOTOR 1 HP 1 SPEED 12.4/6.2 FULL LOAD
OEM
BALDOR
OEM #
VEL11318
Condition
New OEM Original
Returnable
No
CC Number
CC031A
Duty
Continuous
Frame
56C
Full Load Amps
12.4/6.2
HP
1
Hz
60
Includes
Conduit Box
Ins. Class
F
Inverter Rated
Yes
Length Less Shaft
11 23/64 in
Manufacturers Warranty Length
3 yr
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
Capacitor-Start
Motor Efficiency Group
NEMA Premium Efficient
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Rolled Steel
Motor Mounting Position
Horizontal
Motor Mounting Type
Face
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1725
Nominal Efficiency
82.6 %
Number of Speeds
1
Overall Length
13-1/4 in
Phase
1
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
UL, CSA
Voltage
115/230
