P/N: VCJT 1 1/2 Key Specs
Item
FLANGE BEARING 2-BOLT BALL 1-1/2 BORE
OEM
Timken
OEM #
VCJT 1 1/2
Condition
New OEM Original
Returnable
No
Bearing Housing Material Type
Cast Iron
Bearing Insert Material
52100 Chrome Steel
Bearing Insert Type
Ball
Bearing Lubrication
Mobil Polyrex EM or NLGI #2 Equivalent
Bolt Hole Center-to-Center
5 21/32 in
Bolt Size
1/2 in
Bore Dia.
1 1/2 in
Dimension A
1 1/2 in
Dimension B
1 23/32 in
Dimension E
2 7/32 in
Dimension H
6 3/4 in
Dimension J
5 21/32 in
Dimension L
4 1/8 in
Dimension N
33/64 in
Dynamic Load Capacity
8,150 lb
Finish
Powder Coated
Mounted Bearing Item
2-Bolt Flange Bearing
Overall Height
6 3/4 in
Overall Length
4 1/8 in
Overall Width
2 7/32 in
Series
VCJT
Shaft Locking Type
Eccentric Locking Collar
Static Load Capacity
4,400 lb
Temp. Range
-65 Degrees to 200 Degrees F
