P/N: VC-75 Key Specs
Item
VACUUM PUMP 3 HP 3 PHASE 208-230/460V AC
OEM
Rietschle Thomas
OEM #
VC-75
Condition
New OEM Original
Returnable
No
Amps AC
8.8-8.6/4.3
Application
for Vacuum Packaging, Vacuum Chucking, Die Casting, Vacuum Thermoforming and Material Handling
Ballast
Gas
Displacement
49.0 cfm
End Vacuum
29.9 in Hg
Filter
Fine Mesh
Finish
Silver/Gray Metallic
HP
3 hp
Hz
60
Includes
Filter, Oil, Oil Separator, Vacuum Non-Return Valve
Max. dBA
68
Motor Type
TEFC Continuous Duty
NPT Inlet
1 1/4 in
Oil Capacity
96 oz
Overall Height
10 1/2 in
Overall Length
27 11/16 in
Overall Width
13 1/8 in
Phase
3
Voltage
208-230/460
