P/N: UCC10150 Key Specs
Item
MOTOR, 10-15 AIR OVERHP, 3450RPM, 1PH, 60HZ, 215Z, 3
OEM
BALDOR
OEM #
UCC10150
Condition
New OEM Original
Returnable
No
Ambient Temp C
40
Bearing-Drive-End
6307
C-Dimension Inches
18.57
Drive End Flange
Standard
Enclosure
OPEN
Enclosure Type
Open/Drip Proof
Fl Amps
41-57
Fl Efficiency
83
Frame
215Z
Hertz
60
Horsepower
10
Insulation Class
F
Is_Motor
Yes
Kva-Code
C
Motor Rpm 60Hz
3450
Mounting
Rigid
Opposite End Bearing Size
6206
Phase
1
Poles
2
Power-Factor
98
Rpm
3450
Rpm Range
3001-3600
Service Factor
1
Spec. Number
37E764W977
Voltage
230
Weight
128
