P/N: TT-38-15-LB-RS3 Key Specs
Item
COILED AIR HOSE 3/8 ID X 12 FT.
OEM
ATP
OEM #
TT-38-15-LB-RS3
Condition
New OEM Original
Returnable
No
Burst Pressure
420 psi
Compatible Chemicals
Air, Fresh Water
Compressed Length
3 ft
Hose Color
Light Blue
Hose Configuration
Coupled Assembly
Hose Cover Material
Polyurethane
Hose Fitting A Material
Brass
Hose Fitting A Size
3/8 in
Hose Fitting A Type
MNPT
Hose Fitting B Material
Brass
Hose Fitting B Size
3/8 in
Hose Fitting B Type
MNPT
Hose Inside Dia.
3/8 in
Hose Length
12 ft
Hose Outside Dia.
9/16 in
Hose Reinforcement Material
Not Reinforced
Hose Reinforcement Type
Not Reinforced
Hose Strain Relief
Yes
Hose Tube Material
Polyurethane
Max. Working Pressure @ 70 F
140 psi
Not Recommended Chemicals
Acetic Acid 80%, Acetone, Ammonia (Liquids), Anhydrous Ammonia, Automatic Transmission Fluid, Brake Fluid, Chromic Acid 30%, Chromic Acid 50%, Diesel Fuel, Ethyl Acetate, Ethylene Glycol, Formaldehyde, Formaldehyde 40%, Fuel Oil, Gasoline, Heptane, Hexane, Hydraulic Fluid (Petrol
Pigtail Length
20 in
Safety Factor
3:1
Temp. Range
-68 Degrees to 140 Degrees F
