P/N: TR-51626-12 Key Specs
Item
H7803 TIME DELAY RELAY 12VDC 10A DPDT 3 SEC.
OEM
Macromatic
OEM #
TR-51626-12
Condition
New OEM Original
Returnable
No
AC Contact Rating — Relay
10A @ 240V
Adjustment Method — Timer
Potentiometer
Base Type — Plug In Relay
Octal
Body Depth — Relay
1.7 in
Body Height — Relay
2.9 in
Body Width — Relay
2.4 in
Coil Volts
12V DC
Contact Form — Relay
DPDT
Contact Material
Silver Nickel
DC Contact Rating — Relay
10A @ 30V
Electrical Connection
Socket
Function — Timing Relay
Off Delay
Hz — Electrical
50 Hz, 60 Hz
Item — Relay
Single Function Timing Relay
Max Time Setting — Timer
5 min
Min Time Setting — Timer
3 sec
Mounting — Relay
Plug In
Number of Pins — Relay
11
Overall Height — Relay
3.1 in
Power Consumption — Relay
2 W
Socket
1EGP2, 1EGP4, 6X156
Standards
CE, CSA, UR
Status Indicator
None
