P/N: TD-250 Key Specs
Item
STEEL 11 D 7.6 H 7.6 W INLINE DUCT FAN
OEM
S&P USA Ventilation Systems
OEM #
TD-250
Condition
New OEM Original
Returnable
No
Bearing Type
Ball
CFM @ 0.000-In. SP
754/541
CFM @ 0.125-In. SP
715/475
CFM @ 0.250-In. SP
680/418
CFM @ 0.375-In. SP
640/355
CFM @ 0.500-In. SP
606/295
CFM @ 0.750-In. SP
520/218
CFM @ 1.000-In. SP
405/170
CFM @ 1.500-In. SP
245/65
Fits Duct Dia.
10 in
Flange Width
1 1/2 in
Green Certification or Other Recognition
HVI(R) Certified
Housing Dia.
10 3/4 in
Housing Finish
Epoxy
Housing Material
Metal
Hz
60
Includes
Mounting Bracket
Inlet and Outlet Dia.
9 3/4 in
Length
11 1/2 in
Max. Amps
2.2 A
Max. Inlet Temp.
140 Degrees F
Max. Wattage
241/162
Motor Enclosure
Totally Enclosed
Motor HP
1/3 hp
Motor RPM
3200/2400
Mounting Position
Horizontal or Vertical
Number of Speeds
2
Phase
1
Speed Control
Mfr. No. 48C172
Standards
cULus, HVI Certified
Voltage
120V
