P/N: TC1250SE Key Specs
Item
TRUE UNION CHECK VALVE PVC 2-1/2 SOCKET
OEM
Hayward
OEM #
TC1250SE
Condition
New OEM Original
Returnable
No
Application — Valves
General Purpose, Pumps
Body Material — Valves
PVC
Connection Type — Check Valves
Socket x Socket
Cracking Pressure — Check Valves
3 psi
Flow — Valves
100 gpm
Flow Design
Single
Full Flow — Valves
Yes
Item — Check Valves
Check Valve
Length
10-11/16 in
Max Steam Pressure — Valves
Not Rated
Max Temperature — Valves
140 Degrees F
Max Water Pressure — Valves
150 psi @ 70 Degrees F
Mechanism and Body Design
Inline True Union
Min Temperature — Valves
40 Degrees F
Mounting Orientation — Check Valves
Vertical
Overall Height
6-9/16 in
Pipe or Tube Size — Check Valves
2-1/2 in
Seal Material — Check Valves
EPDM
Seat Material — Check Valves
EPDM
Standards
NSF 61
Width
6-9/16 in
