P/N: SUCPA206-19C0FG1 Key Specs
Item
BEARING 1-3/16 BORE DIA SS HOUSING
OEM
NTN
OEM #
SUCPA206-19C0FG1
Condition
New OEM Original
Returnable
No
Bearing Housing Material Type
Stainless Steel
Bearing Insert Material
440C Stainless Steel
Bearing Insert Type
Ball
Bearing Lubrication
FDA/USDA-H1 Solid Grease
Bolt Hole Center-to-Center
3 in
Bolt Size
M10
Bore Dia.
1 3/16 in
Dynamic Load Capacity
3,440 lb
Finish
Unfinished
Includes
(2) Open End Caps
Mounted Bearing Item
Pillow Block Tapped Base Bearing
Mounting Surface to Shaft Center
1 11/16 in
Number of Bolts
2
Overall Height
3 3/8 in
Overall Length
4 in
Overall Width
2 1/16 in
Series
SA-FG1
Shaft Locking Type
Set Screw
Standards
NSF H1 Registered
Static Load Capacity
2,590 lb
Temp. Range
14 Degrees to 212 Degrees F
