P/N: SUCNFL205-16 Key Specs
Item
FLANGE BEARING 2-BOLT BALL 1 BORE
OEM
NTN
OEM #
SUCNFL205-16
Condition
New OEM Original
Returnable
No
Bearing Housing Material Type
PBT
Bearing Insert Material
52100 Chrome Steel
Bearing Insert Type
Ball
Bearing Lubrication
Caltex FM EP or Equivalent USDA-H1 Grease
Bolt Hole Center-to-Center
99 mm
Bolt Size
M10
Bore Dia.
1 in
Dimension A
5 1/8 in
Dimension B
1 11/32 in
Dimension E
3 57/64 in
Dimension G
17/32 in
Dimension L
2 3/4 in
Dimension S
7/16 in
Dynamic Load Capacity
2,680 lb
Finish
None
Mounted Bearing Item
2-Bolt Flange Bearing
Overall Height
70 mm
Overall Length
130 mm
Overall Width
36.7 mm
Series
Corrosion Resistant with USDA-H1 Grease
Shaft Locking Type
Set Screw
Static Load Capacity
1,420 lb
Temp. Range
-4 Degrees to 230 Degrees F
