P/N: SSF721-50K-B5-GS1 Key Specs
Item
SPEED REDUCER C-FACE 56C 50 1
OEM
Boston Gear
OEM #
SSF721-50K-B5-GS1
Condition
New OEM Original
Returnable
No
Base
Optional
Bearings
Tapered Roller
Bore Dia.
5/8 in
Duty
Washdown
Finish
316 Stainless Steel
Frame
56C
Gear Material
Hardened and Ground Steel
Gear Type
Worm
Housing Material
316 Stainless Steel
Input RPM
1,750
Lubrication
Klubersynth UH1 6-460
Max. Input HP
0.5 hp
Max. Output Torque
630 in-lb
Mounting
Any Position
Nominal Output RPM
35
Nominal Ratio
50:1
Number of Stages
1
Output Shaft Dia.
1 in
Output Shaft Height
2 9/32 in
Output Torque @ 1/2 HP
420 in-lb
Output Torque @ 3/4 HP
630 in-lb
Overall Length
8.12 in
Overhung Load
700 lb
Pinion Material
Hardened Steel
Rotation
Forward/Reversible
Seal Type
Double Lip
Shaft Orientation
Right Angle
Single/Double Output/Universal
Single Output
Solid/Hollow Output Shaft
Solid
Speed Reducer Type
C-Face
Standards
NSF
Worm Center Distance
2.06 in
Worm Gear Material
Bronze
