P/N: SPU50-20-TG-L5 Key Specs
Item
PROPANE INFRARED HEATER U-TUBE POSITIVE PRESSURE TOUGH GUY — — 50000 BTU
OEM
Sunstar Heating Products Inc
OEM #
SPU50-20-TG-L5
Condition
New OEM Original
Returnable
No
Btu High
50000
Burner Pressure W.C. Inches
10
Construction
Cast Iron Burner / Aluminum Reflectors
Duct Size Inches
4
Fuel Type
Propane
Gas Inlet Pressure Max. Water Column Inches
14
Gas Inlet Pressure Min. Water Column Inches
11
Height Inches
6-1/4
Ignition Type
Direct Spark
Length Feet
12-3/4
Limited Warranty Years
1
Manufacturer Part#
SPU50-20-TG-L5
Min. Clearance Combustible At 45 Degree Angle Inch
Front 48, Rear 12, Ceiling 6, Below 40, End 30
Min. Clearance Combustibles At Horizontal Inch
Side 27, Ceiling 6, Below 40, End 30
Min. Mounting Height Feet At 45 Degree Angle
10
Min. Mounting Height Feet At Horizontal
11
Shape
U
Tube Construction
Heat Treated Aluminized Steel
Tube Length Feet
20
Type
Positive Pressure
Weight Lbs
120
Width Inches
31
