P/N: SFHA36AT0250 Key Specs
Item
CIRCUIT BREAKER 250A 3P 600VAC SF
OEM
General Electric Company
OEM #
SFHA36AT0250
Condition
New OEM Original
Returnable
No
AC Voltage Rating
600V AC
Amps
250 A
Circuit Breaker Actuator
Toggle
Circuit Breaker Mounting Style
Free Standing
Circuit Breaker Type
Interchangeable Rating Plug, Standard
DC Voltage Rating
Not Rated
Depth
4.79 in
For Use With
Spectra Motor Control Centers, Spectra Powerpanel, Spectra Switchboard
Frame Size
250A/SF
Height
10.12 in
High Amp Trip Setting
2,500 A
Instantaneous Trip
Instantaneous
Low Amp Trip Setting
205 A
Max Air Rating
65kA at 120/240V AC
Max Wire Size
350 MCM
Min Wire Size
8 AWG
Number of Poles
3
Phase
3
Phase Connection
ABC
Series
SF
Standards
CSA Certified, UL Listed
Terminal Connection
Snap In Termination Lug
Trip Type
Electronic
Width
4.13 in
