P/N: SFD212NG4YB07D07 Key Specs
Item
VARIABLE FREQUENCY DRIVE 40 HP 460VAC
OEM
APC / American Power Conversion
OEM #
SFD212NG4YB07D07
Condition
New OEM Original
Returnable
No
Accepts Input Control Signal
Yes
Adjustable Acceleration Time
0.1 to 999.9 sec.
Adjustable Deceleration Time
0.1 to 999.9 sec.
Control Method
Drive or Commas
Depth
12.532 in
Display Type
LCD or Integrated
Displays
Integrated or LCD
Dynamic Braking
Dynamic Deceleration
Enclosure
NEMA 1
Green Environmental Attribute
Product Contributes To Reducing Energy Consumption
Height
12.532 in
Input Frequency
50/60 Hz
Input Phase AC
3
Input Voltage
480VAC
Max HP
40
Max Output Amps
52
Output Frequency Range
0.5 to 200 Hz
Output Phase AC
3
Output Voltage
480VAC
Protection
Circuit Breaker
Start/Stop Control
Yes
Starting Torque
110%
Torque @ 1 Hz
110%
Width
12.532 in
With Bypass / No Bypass
With Bypass
With Line Contactor / No Line Contactor
With Line Contactor
