P/N: S800-1/2 Key Specs
Item
SPRING CHECK VALVE 316 SS 1/2 FNPT
OEM
Bonomi
OEM #
S800-1/2
Condition
New OEM Original
Returnable
No
Application — Valves
General Purpose
Body Material — Valves
316 Stainless Steel
Connection Type — Check Valves
FNPT x FNPT
Cracking Pressure — Check Valves
0.5 psi
Flow — Valves
5.2 gpm
Flow Design
Single
Full Flow — Valves
Yes
Item — Check Valves
Check Valve
Length
2-5/16 in
Max Steam Pressure — Valves
125 psi WSP
Max Temperature — Valves
352 Degrees F
Max Water Pressure — Valves
800 psi
Mechanism and Body Design
Inline Spring
Min Temperature — Valves
0 Degrees F
Mounting Orientation — Check Valves
Horizontal, Vertical
Overall Height
1-11/32 in
Pipe or Tube Size — Check Valves
1/2 in
Seal Material — Check Valves
PTFE
Seat Material — Check Valves
PTFE
Spring Material — Check Valves
Stainless Steel
Width
1-11/32 in
