P/N: S5SS9A-1 Key Specs
Item
SOLENOID AIR CONTROL 1/8 120VAC
OEM
Ingersoll-Rand
OEM #
S5SS9A-1
Condition
New OEM Original
Returnable
No
Ambient Temp. Range
0 Degrees to 122 Degrees F
Body Style
Manifold
Coefficient of Volume
0.25
Electrical Connections
Lead Wire
Max. CFM — Valves
9.0
NEMA Classification
NEMA 4
Operational Pressure Range
22 to 115 psi
Overall Height
1 3/4 in
Overall Length
3 5/16 in
Overall Width
19/32 in
Override
Non-Locking Push
Pipe Size
1/8 in
Pneumatic Valves Product Group
Solenoid Air Control Valve
Shifting Technology
Solenoid/Pilot
Valve Actuator / Return
Solenoid / Spring
Valve Ways and Positions
4-Way/2-Position
Voltage
120V AC
