P/N: S-ZFFM-63FSB-4SL-FB Key Specs
Item
KINGPINLESS PLATE CASTER SWIVEL 3200 LB.
OEM
Hamilton
OEM #
S-ZFFM-63FSB-4SL-FB
Condition
New OEM Original
Returnable
No
Application
Aerospace Tooling, All Purpose Industrial and Commercial Casters, Automotive Assembly Lines, Body Dolly Carts, Casters, Chassis Rack Carts, Engine Dollies, Ergonomic Applications, Material Carts
Caster Brake Type
Swivel Lock with Side Pedal Brake
Caster Frame Material
Steel
Caster Sub-Type
Swivel
Core Color
Silver
Frame Finish
Enamel
Includes
Brake, Swivel Lock
Includes Thread Guards
No
Inside Bolt Hole Spacing
2-7/16 x 4-15/16 in
Load Rating
3200 lb
Mounting Bolt Diameter
1/2 in
Mounting Height
7-1/2 in
Mounting Plate Bolt Hole Pattern
A
Mounting Plate Size
4-1/2 x 6 1/2 in
Non-Marking
Yes
Number of Mounting Holes
4
Number of Wheels
1
Outside Bolt Hole Spacing
3-3/8 in x 5-1/4 in
Replacement Wheel
4DU74
Standards
ICWM
Swivel Construction
Kingpinless
Swivel Lock Type
4-Position Directional Lock
Swivel Raceway Type
Single Ball
Tread Shape
Standard
Wheel Bearing Type
Precision Ball
Wheel Core Material
Forged Steel
Wheel Diameter
6 in
Wheel Width
3 in
Wheel/Tread Color
Silver
Wheel/Tread Hardness Rating
Extra Hard
Wheel/Tread Material
Steel
