P/N: RS15I-A115-TAS-230 Key Specs
Item
ROTARY SCREW AIR COMPRESSOR HORZ 15 HP
OEM
Ingersoll-Rand
OEM #
RS15I-A115-TAS-230
Condition
New OEM Original
Returnable
No
(F)NPT Outlet
1 in
ASME Tank
Yes
Air Dryer Included
Yes
Ambient Temp. Range
36 Degrees to 104 Degrees F
Duty
Continuous
Free Air CFM @ Max. Pressure — Air Compressor
86.0
Full Load Amps
68.0
HP — Air Compressor
20.0 hp
Input Voltage — Air Compressor
230V AC
Item — Air Compressor
Rotary Screw Air Compressor
Max. Pressure — Air Compressor
118 psi
Motor RPM
1,775 RPM
Overall Depth
31.5 in
Overall Height
78 in
Overall Length
75.4 in
Phase — Electrical
3
Refrigerant
R-134a
Tank Size — Air Compressor
120 gal
Tank Style — Air Compressor
Horizontal
dBA @ 3 Feet
74
