P/N: RAYCI1B10L Key Specs
Item
FIXED MOUNT IR TEMP SENSOR 212 TO 932F
OEM
Fluke Networks
OEM #
RAYCI1B10L
Condition
New OEM Original
Returnable
No
Ambient Temperature Range
32 Degrees to 160 Degrees F
Diameter
0.75 in
Environmental Applications
IP 65 (NEMA-4)
Impedance
50 ohm
Includes
(2) Mounting Nuts and Instructions
Loop Resistance
50 kilohm
Manufacturers Warranty Length
2 yr
Repeatability
+/-1% of Measured Value or +/-2 Degrees F, Whichever Is Greater
Response Time
350ms
Sensor Accuracy
+/-2.0%
Sensor Cable Length
10 ft
Sensor Current Rating
20mA
Sensor Emissivity
0.95
Sensor Item
Fixed Mount Infrared Temperature Sensor
Sensor Length
3.5 in
Sensor Measurement Temperature Range
212 Degrees to 932 Degrees F
Sensor Output Type
J Thermocouple
Sensor Power Source
12 to 24V DC
Sensor Spot Size and Distance
1 in @ 4 in
Spectral Response
8 To 14uM
Thread Size
3/4-16 UNF
