P/N: PCR14-4-3-A Key Specs
Item
MOTIONCONTROL COUPLING CLAMP 1/4 X3/16
OEM
Ruland Manufacturing Inc.
OEM #
PCR14-4-3-A
Condition
New OEM Original
Returnable
No
Bore Dia.
1/4 in x 3/16 in
Clearance Dia. (In.)
0.5 in
Clearance Dia. (mm)
12.7
Finish
Bright
Item — Motion Control Couplings
Motion Control Coupling
Length through Bore
0.45 in
Material — Couplings
Aluminum
Max. Angular Misalignment
3 Degrees
Max. Axial Misalignment (In.)
+/-0.005
Max. Bore (In.)
0.25 in
Max. Parallel Misalignment (In.)
0.008 in
Max. RPM
6,000 RPM
Max. Temp.
225 Degrees F
Min. Bore (In.)
0.188 in
Outside Dia.
0.875 in
Overall Length
22.9 mm
Rated Torque
18 in-lb
Screw Size
M3
Screw Type
Cap Screw
Shaft Locking Type — Couplings
1 Piece Clamp
Size
PCR14
Torsional Stiffness (Deg./In.-Lbs.)
0.21
