P/N: P9U901456UC Key Specs
Item
PRESSURE GAUGE 3-1/2 DIAL SIZE BLACK
OEM
Winters Instruments
OEM #
P9U901456UC
Condition
New OEM Original
Returnable
No
Basic Gauge Case Material
Metal
Basic Gauge Lens Material
Plastic
Basic Gauge Sensor Material
Brass
Basic Gauge Socket Material
Brass
Basic Gauge Wetted Parts
Brass
Calibration Certificate Included
No
For Use With
Media Compatible with Bronze
Gauge Accuracy
+/-2-1-2%
Gauge Application
General Purpose
Gauge Case Color
Black
Gauge Case Material
Steel
Gauge Connection Location
Center Back
Gauge Connection Size
1/4 in
Gauge Connection Type
MNPT
Gauge Lens Material
Acrylic
Gauge Mounting Method
U Clamp
Gauge Nominal Dial Size
3-1/2 in
Gauge Panel Mountable
Yes
Gauge Primary Range Numbered Graduations
5/50
Gauge Primary Range Smallest Graduation
1/10
Gauge Primary Range Units
psi
Gauge Primary Range Values
0 to 30
Gauge Secondary Range Units
kPa
Gauge Secondary Range Values
0 to 200
Gauge Sensor Material
Brass
Gauge Socket Material
Brass
Gauge Special Options
Zero Adjustment Screw
Liquid Filled
No
Manufacturers Warranty Length
5 yr
Operating Temperature Range
-40 Degrees to 150 Degrees F
Pressure and Vacuum Gauge Type
Pressure Gauge
Series
P9U
