P/N: NV2FG42BSG Key Specs
Item
CFL FIXTURE WITH 2PDH1 2PDG7 AND 2PDG8
OEM
Killark
OEM #
NV2FG42BSG
Condition
New OEM Original
Returnable
No
Ambient Temperature Range
-40 Degrees F
Ballast Quantity
1
Bulb Designation
GX24-Q-3
Description/Special Features
Non-Metallic Corrosion Resistant, Designed for Indoor and Outdoor Globe Down Applications
Dimmable
No
Emergency Battery Backup
No
Fixture Ballast Type
Electronic
Fixture Type
Hazardous Location
Fixture Type — Decorative and Surface Mount Fixtures
Hazardous Location Pendant
Fixture Voltage
120 to 277
Fixture Wattage
42
Height
13-3/8 in
Housing Finish
Gray
Housing Material
30% Glass Filled Thermoset Polyester
IP Rating
66
Includes
2PDH1 Glass Globe, 2PDG7 Splice Box And 2PDG8 Wall Bracket
Item — Decorative and Surface Mount Fixtures
Traditional Surface Mount Fixture
Lamp Included
No
Lamp Quantity
1
Lamp Type
Fluorescent
Lamp Type — Fixtures
GX24-Q-3
Lamp Watts
42
Lamp Watts — Fixtures
42
Length
4-3/8 in
Lighting Technology
Fluorescent
Linkable Up To
Unlinkable
Max Fixture Wattage
42
Mounting
Wall
Nominal Height
13-3/8 in
Nominal Length
4-3/8 in
Nominal Width
7-5/16 in
Series
NV2
Standards
Class I, Div 2 Groups A, B, C, D, Class I, Zone 2, Groups IIC, IIB, IIA, Class II, Div 2, Groups F, G, Class III, UL Marine Rated for US, NEMA 3, 4, 4X, IP66
Suggested Lamp Item Number
1PHA7
Voltage
120 to 277VAC
Width
7-5/16 in
