P/N: NCDMC056-0800 Key Specs
Item
AIR CYLINDER 9/16 IN BORE 8 IN STROKE
OEM
Speedaire
OEM #
NCDMC056-0800
Condition
New OEM Original
Returnable
No
Air Cylinder Bore Dia.
9/16 in
Air Cylinder Mount
Pivot
Air Cylinder Product Group
Air Cylinder
Air Cylinder Type
Round Body
Body Material
Stainless Steel
Bore Dia.
9/16 in
Cushion Type
None
Cylinder Action
Double Acting
Cylinder Type
Round
End Cap Material
Aluminum
Finish
Hard Coat Anodized
Magnetic Piston
Yes
Max. Pressure
250 psi
Mount
Pivot
Nose Mount Thread
7/16-20 UNF
Overall Length
11.25 in
Piston Material
Magnetic
Piston Rod Material
Chrome Plated Carbon Steel
Pivot Hole Dia.
0.157 in
Port Size
#10-32 UNF
Rod Dia.
0.197 in
Rod Thread Length
0.5 in
Rod Thread Size
#10-32 UNF
Single Acting/Double Acting
Double Acting
Stroke
8 in
Temp. Range
40 Degrees to 140 Degrees F
Tie Rod Material
N
Tube Material
Stainless Steel
