P/N: NCDMB088-0200CS Key Specs
Item
AIR CYLINDER 7/8 IN BORE 2 IN STROKE
OEM
Speedaire
OEM #
NCDMB088-0200CS
Condition
New OEM Original
Returnable
No
Air Cylinder Bore Dia.
7/8 in
Air Cylinder Mount
Nose
Air Cylinder Product Group
Air Cylinder
Air Cylinder Type
Round Body
Body Material
Stainless Steel
Bore Dia.
7/8 in
Cushion Type
Rubber Bumper
Cylinder Action
Single Acting
Cylinder Type
Round
End Cap Material
Aluminum
Finish
Hard Coat Anodized
Magnetic Piston
Yes
Max. Pressure
250 psi
Mount
Nose
Nose Mount Thread
5/8-18 UNF
Overall Length
5.46 in
Piston Material
Magnetic
Piston Rod Material
Stainless Steel
Port Size
1/8 in NPT
Rod Dia.
0.25 in
Rod Thread Length
0.5 in
Rod Thread Size
1/4-28 UNF
Single Acting/Double Acting
Single Acting
Spring Extension Force
3 lb
Spring Retraction Force
6 lb
Stroke
2 in
Temp. Range
40 Degrees to 140 Degrees F
Tie Rod Material
N
Tube Material
Stainless Steel
