P/N: MOST41-17-A Key Specs
Item
OLDHAM COUPLING HUB SET SCREW 17MM
OEM
Ruland Manufacturing Inc.
OEM #
MOST41-17-A
Condition
New OEM Original
Returnable
No
Assembled Coupling Length
50.8 mm
Bore Dia.
17 mm
Clearance Dia. (In.)
1.625 in
Clearance Dia. (mm)
41.3
Finish
Black Anodized
Item — Oldham Coupling Hubs
Oldham Coupling Hub
Length through Bore (In.)
0.71 in
Length through Bore (mm)
18
Material — Hubs
Aluminum
Max. RPM
4,500 RPM
Max. Temp. Range (F)
Acetal Disk 150 Degrees F, Nylon Disk 130 Degrees F
Outside Dia.
41.3 mm
Overall Length (In.)
0.71 in
Overall Length (mm)
18.0
Screw Size (mm)
M5
Screw Type
Set Screw
Setscrew Location
2 (90 Degrees )
Shaft Locking Type — Couplings
1 Piece Set Screw
Size
MOST41
With Keyway / Without Keyway
Without Keyway
