P/N: M9F22240 Key Specs
Item
IEC SUPP PROTECTOR 40A 240/415/440VAC 2P
OEM
APC / American Power Conversion
OEM #
M9F22240
Condition
New OEM Original
Returnable
No
AC Voltage Rating
240/415/440V AC
Amps
40 A
Application
Branch Circuit Protection
Circuit Breaker Actuator
Toggle
Circuit Breaker Mounting Style
DIN Rail
Curve Type
C
DC Voltage Rating
Not Rated
Depth
2.83 in
Length
3.19 in
Max Air Rating
10kA at 240V AC
Max Wire Size
2 AWG
Meets UL Type
UL 1077
Min Wire Size
18 AWG
Number of Poles
2
Phase
1
Series
C60SP
Standards
CCC, CSA C22.2 No 235, EN/IEC 60947-2, GB 14048.2, UL 1077, UR
Terminal Connection
Screw Clamp
Trip Type
Thermal Magnetic
Width
1.42 in
