P/N: HD2100DKB-83 Key Specs
Item
CONTINUOUS HINGE DARK BRONZE ANODIZED
OEM
National Guard Products
OEM #
HD2100DKB-83
Condition
New OEM Original
Returnable
No
ADA Compliant
Yes
Door Leaf Height
83 in
Door Leaf Thickness
0.125 in
Door Leaf Width
2-11/16 in
Finish
Dark Bronze Anodized
Frame Leaf Height
83 in
Frame Leaf Thickness
0.125 in
Frame Leaf Width
1-5/8 in
Hardware
Included
Hole Spacing
12 in
Holes
With
Holes per Leaf
13 and 16
Length
83 in
Ligature Resistant
No
Load Capacity
600 lb
Material
Aluminum Alloy
Mounting
Full Surface
Orientation
Reversible
Overall Knuckle Height
7/8 in
Overall Width
3-1/16 in
Range of Motion
180 Degrees
Required Door Thickness
1-3/4 in to 2-1/4 in
Standards
ANSI/BHMA certified to A156.26 American National Standard for Continuous Hinges
UL Fire Rating
UL10C
