P/N: FE1056SU Key Specs
Item
CONDENSER FAN MOTOR 1/2 HP 1075 RPM 3.8
OEM
Regal Beloit America, Inc. (Century Electric Motors)
OEM #
FE1056SU
Condition
New OEM Original
Returnable
No
Application
Condenser Fan
Body Diameter
1/2 in
Bolt Circle Diameter
1/2 in
Capacitor Required
2MDV7
Duty
Continuous
Frame
48
Full Load Amps
3.8
HP
1/2
Hz
60
Ins. Class
F
Lead Length
48 in
Length Less Shaft
1/2 in
Max Ambient Temperature
80 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Totally Enclosed Air-Over
Motor Mounting Position
All Angle
Motor Mounting Type
Stud
Motor Service Factor
1
Motor Shaft Design
Double-Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Condenser Fan
Motor Thermal Protection
Auto
Mounting Stud Pattern
1/2 in
Nameplate RPM
1075
Number of Speeds
1
Overall Length
1/2 in
Phase
1
Shaft Diameter
1/2 in
Shaft Length
1/2 in
Standards
CSA Certified (LR43341), UL Recognized (E46412)
Stud Quantity
4
Stud Size
8-32
Voltage
208-230
