P/N: ET2815C Key Specs
Item
ELECTRONIC TIMER ASTRO 7/365 DAYS 20A
OEM
Intermatic
OEM #
ET2815C
Condition
New OEM Original
Returnable
No
Amps
20 A
Available Actions — Electronic Timer
On/Off
Backup Device
Capacitor
Backup Time
100 hr
Color
Gray
Contact Form
SPDT
Depth
3-7/16 in
Description/Special Features
Indoor
Display Height
1 in
Display Width
3 in
Enclosure
Metal
Event Allocation — Electronic Timer
1 On/Off Action = 2 Events
Events Available — Electronic Timer
96
HP @ 120V
1
HP @ 240V
2
Height
7-7/8 in
Max Time Setting
7 day
Min Time Setting
1 min
Mounting
Surface
NEMA Rating
1
Number of Channels
1
Number of Poles
1
Operating Temperature
-40 Degrees to 155 Degrees F
Operation Mode
Astro 7/365 Days
Standards
California Title 20 Listed, LED Listed, UL Listed
Voltage
120 to 277V AC
Width
5-1/8 in
