P/N: ES85-12-G Key Specs
Item
COMMERCIAL WATER HEATER 85 GAL. 480VAC
OEM
Rheem
OEM #
ES85-12-G
Condition
New OEM Original
Returnable
No
Amps AC
25 for 1 Phase, 15 for 3 Phase
Commercial / Residential
Commercial
Compliance
Tested According to DOE Test Procedures and Exceed the Minimum Energy Factor Requirements of Current ASHRAE Standards, Exceeds Energy Effeciency Codes of all States. Design Certified by Underwriters Laboratory (UL) to Meet UL Standard 1453 and UL/NSF005.
Connection Location
Side
Height to Cold Side Connection
4-3/4 in
Height to Hot Side Connection
1-1/2 in NPT
Includes
T and P Valve, Full Port/Full Flow Brass Drain Valve, System Sentinal
Item — Water Heaters
Electric Water Heater
Jacket Diameter
1-1/2 in NPT
Manufacturers Warranty Length
3 yr. Limited Tank, 1 yr. Limited Parts
Max Pressure
150 psi
Number of Elements
3
Overall Height — Water Heaters
1-1/2 in NPT
Overall Width
34 in
Phase — Water Heaters
1/3
Recovery @ 100 F Rise
50 gph
Recovery @ 110 F Rise
45 gph
Recovery @ 120 F Rise
41 gph
Recovery @ 130 F Rise
38 gph
Recovery @ 140 F Rise
35 gph
Recovery @ 50 F Rise
99 gph
Recovery @ 70 F Rise
71 gph
Recovery @ 90 F Rise
55 gph
Standards
UL Certified
Tank Capacity — Plumbing
85 gal.
Temperature Range
120 Degrees to 180 Degrees F
Total Watts
12,000
Voltage — Water Heaters
480
Water Connection
1-1/2 in NPT
Water Heater Design
Whole House
