OEM#: ERM3158TAHVAC MOTOR, 3 PH, 3 HP, 208-230/460 V, 3450 RPM, OPEN, 56HZ FRAME by BALDOR

220 050

Baldor-Reliance HVAC Motor, ERM3158TA, 3 PH, 3 HP, 208-230/460 V, 3450 RPM, OPEN, 56HZ FrameBaldor-Reliances line of Heating, Ventilation, and Air Conditioning Motors are designed with dynamically balanced rotors for reduced vibration and quiet operation. The motors range in size from 1/4 HP to 100 HP and include heavy duty industrial designs as well as designs for commercial applications. These applications include ventilators, direct drive and belted fans, exhaust fans, unit heaters, air conditioning units, and commercial refrigeration condensers. Also included are motors designed especially for use with variable torque electronic controls that are used to conserve electricity.FeaturesHeavy gauge steel baseBall bearingsSuitable for mounting in any positionDynamically balanced rotors for reduced vibration and quiet operationApplication(s)Ventilators, summer cooling fans, band saws drill presses, farm equipment.

Доставка импортных компонентов по России от 3х недель транспортными компаниями СДЭК, Деловые Линии, Major Express.
Оплата физическими и юридическими лицами безналичным расчетом.
Цена может измениться после запроса у поставщика!
Артикул: HomeBALDORERM3158TA TME арт.: HomeBALDORERM3158TA

P/N: ERM3158TA Key Specs

Item
HVAC MOTOR, 3 PH, 3 HP, 208-230/460 V, 3450 RPM, OPEN, 56HZ FRAME
OEM
BALDOR
OEM #
ERM3158TA
Condition
New OEM Original
Returnable
No
Ambient Temp C
40
Approvals Or Certifications
CSA, CSA EEV, UR
Bearing Type
Ball
Design Code
B
Drive End Bearing Size
6205
Duty
Continuous
Enclosure
OPEN
Enclosure Type
Open/Drip Proof
Fl Amps
8-7.6/3.8
Fl Efficiency
85.5
Frame
56HZ
Frame Size
364T
Full Load Amps
8.0/7.6/3.8
Height Inches
11
Hertz
60
Horsepower
3
Insulation Class
H
Is_Motor
Yes
Length Inches
18.5
Length Less Shaft Inches
40.5
Motor Rpm 60Hz
3450
Mounting
Resilient
Opposite End Bearing
6203
Opposite End Bearing Size
6203
Overall Length
13.64
Phase
3
Rated Rpm
3450
Rotation
CCW/CW
Rpm Range
3001-3600
Service Factor
1.15
Shaft Diameter
0.875
Shaft Diameter Inches
1.875
Speeds
1
Thermal Protection
Automatic
Voltage
208-230/460
Weight Lbs
907
Width Inches
10.5
