OEM#: EM2546TMOTOR, 60HP, 3540RPM, 3PH, 60HZ, 326TS, 4252M, OPSB, F by BALDOR

1 669 050

Baldor-Reliance Motor, 60HP,3540RPM,3PH,60HZ,326TS,4252M,OPSB,FFeatures:Heavy duty framesBall bearingsMoisture resistant ISR® (Inverter Spike Resistant) copper windingsLow-loss electrical lamination grade steelThree year warranty.Typical Applications:Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.

Доставка импортных компонентов по России от 3х недель транспортными компаниями СДЭК, Деловые Линии, Major Express.
Оплата физическими и юридическими лицами безналичным расчетом.
Цена может измениться после запроса у поставщика!
Артикул: HomeBALDOREM2546T TME арт.: HomeBALDOREM2546T

P/N: EM2546T Key Specs

Item
MOTOR, 60HP, 3540RPM, 3PH, 60HZ, 326TS, 4252M, OPSB, F
OEM
BALDOR
OEM #
EM2546T
Condition
New OEM Original
Returnable
No
Ambient Temp C
40
Bearing-Drive-End
6312
Bearing-Opp-Drive-End
6311
C-Dimension Inches
25.19
Design Code
B
Drive End Flange
Standard
Enclosure
OPSB
Enclosure Type
Open/Drip Proof
Fl Amps
130/65
Fl Efficiency
94.5
Frame
326TS
Grease
POLYREX EM
Hertz
60
Horsepower
60
Insulation Class
F
Is_Motor
Yes
Kva-Code
H
Motor Rpm 60Hz
3540
Mounting
Rigid
Nameplate Rpm
3540
Phase
3
Poles
2
Power-Factor
92
Rpm Range
3001-3600
Service Factor
1.15
Spec. Number
42F058W411G1
Voltage
230/460
Weight
463
