P/N: EL3503 Key Specs
Item
MOTOR 3450RPM 1PHASE 56 115/230V 1/2 HP
OEM
BALDOR
OEM #
EL3503
Condition
New OEM Original
Returnable
No
CC Number
CC031A
Duty
Continuous
Frame
56
Full Load Amps
4.9/2.5
HP
1/2 hp
Hz
60
Includes
Conduit Box
Ins. Class
B
Inverter Rated
No
Length Less Shaft
10 3/32 in
Manufacturers Warranty Length
3 yr
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
Capacitor-Start
Motor Efficiency Group
Energy Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Rolled Steel
Motor Mounting Position
Horizontal
Motor Mounting Type
Rigid Base
Motor Service Factor
1.25
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
3450
Nominal Efficiency
68 %
Number of Speeds
1
Overall Length
12 in
Phase
1
RPM Group
3001-3600
RPM Range
3001-3600
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
CSA, UL
Voltage
115/230
