P/N: ED41B090 Key Specs
Item
CIRCUIT BREAKER 90A 1P 120/277VAC ED4
OEM
Siemens
OEM #
ED41B090
Condition
New OEM Original
Returnable
No
AC Voltage Rating
120/277V AC
Amps
90 A
Circuit Breaker Actuator
Toggle
Circuit Breaker Mounting Style
Lug In Panelboard
Circuit Breaker Type
Standard
DC Voltage Rating
125V DC
Depth
4 in
For Use With
SB Switchboards, Sentron Panelboards
Frame Size
125A/ED
Height
6.34 in
High Amp Trip Setting
90 A
Instantaneous Trip
Fixed
Low Amp Trip Setting
90 A
Max Air Rating
22kA at 277V AC
Max Wire Size
1/0 AWG
Min Wire Size
6 AWG
Number of Poles
1
Phase
1
Phase Connection
Any
Series
ED4
Standards
IEC Certified, UL Listed
Terminal Connection
Load Side Lug
Trip Type
Thermal Magnetic
Width
1 in
