P/N: E57P-18UNC8-C2 Key Specs
Item
PROXIMITY SENSOR 8MM DETECT DIST 1200 HZ
OEM
Eaton
OEM #
E57P-18UNC8-C2
Condition
New OEM Original
Returnable
No
Basic Proximity Sensor Case Material
Metal
Case Material
Stainless Steel
Description/Special Features
Proximity Switch-Performance
IP Rating
69K
Length
66 mm
Max Current Load
300mA
Max Detecting Distance
8 mm
NEMA Rating
4X
Operating Temperature Range
-40 Degrees to 158 Degrees F
Output Mode
NC
Proximity Sensing Method
Inductive
Proximity Sensor Diameter
18 mm
Proximity Sensor Electrical Connection
2m Cable
Proximity Sensor Operating Frequency
1,200 Hz
Proximity Sensor Output Circuit Type
3 Wire NPN
Proximity Sensor Power Requirement
10 to 48V DC
Shielded / Unshielded
Unshielded
Standards
CE Compliance, cUL Listed, UL Listed
