Name: OEM#: E5034XNNTS1DOUBLE SEALED SHEAVE BEARING E5040W33NRNT, WITH SNAP RINGS &amp; COATING, 200MM BORE, 310MM OD by Nachi America Inc
SKU: HomeNachi America IncE5034XNNTS1
Availability: InStock

OEM#: E5034XNNTS1DOUBLE SEALED SHEAVE BEARING E5040W33NRNT, WITH SNAP RINGS & COATING, 200MM BORE, 310MM OD by Nachi America Inc

760 050 ₽

NACHI Double Sealed Sheave Bearing E5040W33NRNT, With Snap Rings & Coating, 200MM Bore, 310MM ODFeaturesNACHI Sheave Bearing is a Double Row Full Compliment Cylindrical Roller BearingSince the bearing carries the highest Dynamic & Static Load Ratings, it is highly recommended for Rope Sheave applicationsIf snap rings are used on both sides of outer ring, it is easy to set the axial location of the bearingRe-lubrication can be done through lubrication holes and groove on the inner ring or outer ring (for certain items)Operating temperature range is -30° to 80°C (-35° to 175°F)

Доставка импортных компонентов по России от 3х недель транспортными компаниями СДЭК, Деловые Линии, Major Express.

Оплата физическими и юридическими лицами безналичным расчетом.

Цена может измениться после запроса у поставщика!

Артикул: HomeNachi America IncE5034XNNTS1 TME арт.: HomeNachi America IncE5034XNNTS1

Nachi America Inc

P/N: E5034XNNTS1 Key Specs

Item

DOUBLE SEALED SHEAVE BEARING E5040W33NRNT, WITH SNAP RINGS & COATING, 200MM BORE, 310MM OD

OEM

Nachi America Inc

OEM #

E5034XNNTS1

Condition

New OEM Original

Returnable

Axial Limiting Load (N)

2,650,000

Bearing Style

With Snap Rings & Coating

Bore Diameter Millimeters

200

Cage Type

None

Dynamic Load Rating (N)

1,300,000

Inner Width Millimeters

150

Max Speed / Grease (Rpm)

500

Oil Holes/Groove On Outter Ring

Inner & Outer Rings

Outer Diameter Millimeters

310

Outer Width Millimeters

149

Radial Clearance

0.070 to 0.140 mm

Snap Groove B (Mm)

6.3

Snap Groove Cg (Mm)

128.2

Snap Groove D1 (Mm)

304.0

Tolerance

ISO Normal
