P/N: D53RV50CH Key Specs
Item
REV SOLID STATE RELAY IN 4 TO 32VDC 50
OEM
CRYDOM
OEM #
D53RV50CH
Condition
New OEM Original
Returnable
No
Body Depth — Relay
3.14 in
Body Height — Relay
1.39 in
Body Width — Relay
3.99 in
Case Color
Gray
Contact Form — Relay
(3) SPST-NO
Finger Safe
Yes
Heat Sink
Not Included
Includes
Thermal Pad
Input Power Consumption (Burden)
0.3W
Input or Control Voltage
4 to 32V DC
Item — Relay
Reversing Solid State Relay
Max Output Amps Without Heat Sink
Not Recommended
Max Output Amps w/Heat Sink
50
Mounting — Relay
Surface
Output or Controlled Voltage Range
48 to 530V AC
Overall Height — Relay
1.39 in
Relay Turns On At
Instantaneous/Random
Standards
CE, UL
Switch Type
SCR
